Getting Started

Package Contents

Your NIX labs AL60 includes the following items:

• NIX labs AL60 LED Ring Clock
• Desk stand (3 pieces)
• USB-C Power Adaptor (Region-specific)
• Quick-Start Guide

Assembly

Desk Stand

1. Press the rectangular horizontal support into the slots on the two triangular pieces.

2. Insert the triangular pieces into the back of the clock as shown and route the USB cable above or below the horizontal support as required.

   Tip

   There are two sets of holes to allow for adjustable display angles. Use the upper holes for a gentle slope or the lower holes for a more upright position.

Wall Mounting

1. Position a protruding nail or picture hook (not provided) at the desired position on the wall near a power outlet.

2. Align the larger part of the keyhole on the back of the clock with the hook and lower it into position.

   Note

   We recommend setting the time before installing the clock on the wall. Time and settings are stored even when power is disconnected.

   The clock has rubber feet pre-installed on the back to allow space for the cable to exit.

Powering Up

1. Connect the USB-C cable to the port located on the back of the clock.

2. Plug the adaptor into a wall outlet and switch it on.

3. The clock will power up immediately. Either connect the clock to Wi-Fi to enable internet time sync or manually set the time using the buttons.

Other Power Sources

A quality power supply is important for achieving maximum display brightness and reliability. NIX labs recommends using only the supplied power adaptor when running from mains power and only high quality USB data cables when connected to a computer or other device.

If an alternative adaptor is used, ensure it meets these requirements:

• Output: 5.0-5.1V and rated for at least 3A.
• Compliance: Must carry the required regulatory safety and compliance markings for your country (e.g. Australian RCM and/or UL mark).
